WATER FLOW DETECTOR-WFDEN

Shipping calculated at checkout.

SHORT DESCRIPTIONS

PRESSURE RATING: LPC: 17.25 BAR (250 PSI)
VdS: PN16 (16 BAR, 232 PSI)
WORKING TEMPERATURE: 0°C to 49°C (32°F to 120°F)
CONTACT RATINGS: Two sets of SPDT (Form C)
10.0 A, ½ HP @ 125/250 VAC
2.5 A @ 6/12/24 VDC
PIPE SIZE: 50mm to 200mm (2″ to 8″)
COMPATIBLE PIPE: Steel water pipe, schedule 10 through 40
CONDUIT ENTRANCES: Two openings for 15mm (½”) conduit
COVER TAMPER SWITCH: Standard with ULC models, optional for UL and European models
ENCLOSURE RATING: IP56
MAXIMUM SURGE: 5.5 metres per second (18 ft/s)
TRIGGERING THRESHOLD: 30-57 LPM (6.6-12.5 GPM)
TIME DELAY: Adjustable 0 to 30seconds
APPROVALS: FM Approved, LPCB, VdS, CE, Gost

DATA SHEET 2.07 B[EN]
WATER FLOW SWITCH – CE CERTIFICATE
WFDEN FLOW SWITCH – GOST CERTIFICATE
